Protege FS8

8″ Dual-Drive Powered Sub w/ 200W Amp – Black

No music or movie experience is complete without bass, but in many cases there’s just no room for a subwoofer. Well, not for an average subwoofer—but the FS8 is no average subwoofer. With an 8-inch driver, an 8-inch passive radiator and a 200-watt amp, this tiny sub puts out serious couch-shaking power.

Description

Big boom for small rooms.
The FS8 is the perfect subwoofer for places where you never thought you could use a subwoofer. Like bedrooms, designer living rooms and home offices. At less than 14 inches on its longest side, the FS8 can easily hide behind couches, sit under end tables or nestle in a corner.

Yet there’s nothing tiny about the FS8’s performance. We gave it an 8-inch composite driver with an extra-wide surround to increase the cone excursion, which dramatically increases deep bass power. We powered the driver with a 200-watt Class D amp, and added an 8-inch passive radiator to reinforce the deepest bass notes. The result is a minisub with serious slam—and a fast, musical sound that’ll thrill both audiophiles and action-movie fans.

Features

8″ Front-Firing Polypropylene-Coated Fiber Composite Woofer
8″ Down-Firing Passive Radiator

Type: Class D Amp
Power Rating Continuous: 200 Watts RMS

Power Rating Peak: 400 Watts Peak
Frequency Response: 32Hz – 150Hz

Subwoofer Output: 100dB SPL
Inputs: Left & Right Line Level, LFE

Outputs: Line Level High-Pass
Phase Switch: 0 – 180 °

Crossover: 50Hz – 150Hz; Bypass
Arotection: Anti-Clipping Circuitry
Power On/Off: Auto Sensing

Black Wood Grain with Dampened Rubber Feet
Dimensions: H 13-5/8″ x W 11-3/4″ x D-12 1/2″

Specifications

8″ Front-Firing Polypropylene-Coated Fiber Composite Woofer
8″ Down-Firing Passive Radiator

Type: Class D Amp
Power Rating Continuous: 200 Watts RMS

Power Rating Peak: 400 Watts Peak
Frequency Response: 32Hz – 150Hz

Subwoofer Output: 100dB SPL
Inputs: Left & Right Line Level, LFE

Outputs: Line Level High-Pass
Phase Switch: 0 – 180 °

Crossover: 50Hz – 150Hz; Bypass
Arotection: Anti-Clipping Circuitry
Power On/Off: Auto Sensing

Black Wood Grain with Dampened Rubber Feet
Dimensions: H 13-5/8″ x W 11-3/4″ x D-12 1/2″

Other Specifications

General
  • FamilySubwoofers
  • Woofer Size8 (Inches)
Shipping Info
  • Length17.7 (Inches)
  • Width17 (Inches)
  • Height18.3 (Inches)
  • Weight25.3 (Lbs)
  • Unit of MeasureEach
  • UPC664254020018
  • Master Pack Qty1
Other Specifications
  • 8″ Front-Firing Polypropylene-Coated Fiber Composite Woofer
  • 8″ Down-Firing Passive Radiator
  • Type: Class D Amp
  • Power Rating Continuous: 200 Watts RMS
  • Power Rating Peak: 400 Watts Peak
  • Frequency Response: 32Hz – 150Hz
  • Subwoofer Output: 100dB SPL
  • Inputs: Left & Right Line Level, LFE
  • Outputs: Line Level High-Pass
  • Phase Switch: 0 – 180 Degrees
  • Crossover: 50Hz – 150Hz; Bypass
  • Protection: Anti-Clipping Circuitry
  • Power On/Off: Auto Sensing
  • Black Wood Grain with Dampened Rubber Feet
  • Dimensions: H 13 5/8″ x W 11 3/4″ x D 12 1/2″
Shipping Info
  • Length17.7 (Inches)
  • Width17 (Inches)
  • Height18.3 (Inches)
  • Weight25.3 (Lbs)
  • Unit of MeasureEach
  • UPC664254020018
  • Master Pack Qty1
Other Specifications
  • 8″ Polypropylene-Coated Fiber Composite Woofer
  • 8″ Down-Firing Passive Woofer
  • Type: Class D Amp
  • Power Rating Continuous: 200 Watts RMS
  • Power Rating Peak: 400 Watts Peak
  • Frequency Response: 32Hz – 150Hz
  • Subwoofer Output: 100dB SPL
  • Inputs: Left & Right Line Level, LFE
  • Outputs: Line Level High-Pass
  • Phase Switch: 0 – 180 Ohms
  • Crossover: 50Hz – 150Hz; Bypass
  • Black Wood Grain with Dampened Rubber Feet
  • Dimensions: H 13 5/8″ x W 11 3/4″ x D 12 1/2″

Warranty

LIMITED THREE-YEAR WARRANTY
